Key Features
- Advanced design reduces light pollution and improves spectator viewing
- Precise optical control designed specifically for sport
- Robust for all environments with an IP66 and IK10 rating
- Lens and lumen packages available in a versatile design for multiple applications
- Dali and DMX options
- Full cut off low spill design for control of light
Technical Specifications
| Challenger 3 LED | |||
|---|---|---|---|
| Power (W) | 1000W | 1500W | 1800W |
| Weight (without driver) | 25.7kg | 33.8kg | 33.8kg |
| Lumen output | up to 162,865 | up to 244,298 | up to 274,637 |
| LED chips numbers | 224 pcs | 120 pcs | 288 pcs |
| Light efficiency | up to 159lm/W | ||
| Beam angle | 17°, 25° and 50° options available | ||
| Colour temperature | 4000 – 6000K (5700 standard) | ||
| Colour rendering index (CRI) | ≥70 (≥90 optional) | ||
| Colour | Heat Sink: Ral 9017, Bracket: Ral 9017 & Abacus red | ||
| IP rating | IP66 | ||
| IK rating | Ik10 | ||
| Operating temperature range | -40° – +40° (module) | ||
| Module adjustable angle | -20° – +90° | ||
| Optional accessories | Front glass, DALI/DMX, Shields, Aiming device | ||
| Driver information | 1500W driver is 3ch. DALI2/DMX driver, 7.0kg (including mounting arrangements) | ||
