A compact full cutoff wall mounted luminaire available in two Wattages. With a specially designed wide forward throw optical distribution, it replaces an HID lighting system of up to 150W MH or HPS.
Typical applications include; rail, ports, warehouses, retail and amenity.
Mounting heights between 3 – 8 metres can be used based on light level and uniformity requirements.
Key Technical Features
- Die cast aluminium housing with full cut off front frame, integral heat sink and driver compartment.
- Twist-lock photocell / smart controls adaptable.
- Nickel-plated stainless steel hardware.
- Black (RAL 9005) powdercoat finish over a chromate conversion coating.
- Clear one-piece molded Type IV polycarbonate lens.
- Includes Easy-Hang wall mounting bracket with built-in level.
- Optional trim plate is available for use in retrofit applications to cover wall surface blemishes.
- Electronic driver, 120-277V, 50/60Hz; Power factor >0.90. Standard internal surge protection is 2kV for 25W, 6kV for 37W. 0-10V dimming as standard.
- CE: Listed for wet locations.
- IP66 sealed LED compartment.
- 5-year warranty.
- Designed to operate in -40°C to +50°C environment.
- CRI: 80
- CCT: 4,000K (standard) & 5,000K
- L90 (25°C ambient): >100,000 hours
